Mig Welder | Kemppi MinarchMig Evo 200

Mig Welder the Kemppi MinarchMig Evo 200 Adaptive MIG/MAG Welder offers Automatic and Manual mode set-up for precise welding quality and arc ignition, monitored and controlled by Kemppi’s adaptive arc regulation system. MinarcMig Evo 170 offers manual setting only, with separate controls for voltage and wire feed speed.

FEATURES:

• Precise weld quality and arc ignition.
• 200 or 170 A of MIG/MAG welding power from a 16 A supply.
• Choose either Automatic or Manual model.
• Use with Fe, Fe FCW, Ss, Al, CuSi filler wires, 1 kg and 5 kg spools.
• With 200 A model, just set the plate thickness and start welding.
• Large graphical display guides user.
• Designed for use with long supply cables of 100 m and more.
• A 3-meter gun, cable set and carrying strap included.
• Suitable for mains network or generator use.

SPECIFICATIONS:

• Connection voltage 1~ 50/60 Hz: 240 V ± 15 %
• Rated power at max. current 35 % ED: 200 A / 4.8 kVA
• Output (40 ºC)

  • 35 % ED: 200 A / 24 V
  • 100 % ED: 120 A / 20 V
• Power factor at 100 %: ED 0.99
• Efficiency at 100 %: ED 82 %
• Wire spool max. diameter: 200 mm
• Wire spool max. weight: 5 kg
• EMC class: A
• Dimensions (L x W x H): 450 x 227 x 368 mm
• Weight: 13 kg
